Backstage Meets Kubernetes: A Complete Guide to the Kubernetes Backend Plugin

Jun 25, 2026

—

Hello everyone! Today, we’re going to dive deep into a core component that enables one of Backstage’s powerful features, Kubernetes integration: the Kubernetes backend plugin. 🚀

In a cloud-native environment, when operating a developer portal (Backstage), it’s crucial to see at a glance how your services are running on a Kubernetes cluster (Pod status, deployment status, etc.). Let’s meet the star responsible for this magical connection right now! 💡

🏗️ The answer is: @backstage/plugin-kubernetes-backend ☸️

The core backend plugin that integrates Kubernetes resource data into the Backstage portal and provides APIs is @backstage/plugin-kubernetes-backend.

This plugin plays a pivotal role in querying actual Kubernetes resources (Pods, Deployments, Services, Ingress, etc.) related to each service (Entity) and delivering them to the frontend.

🌟 Key Roles of the Kubernetes Backend Plugin

Beyond simply fetching data, this plugin performs the following complex tasks:

1. Multi-cluster Data Collection (Multi-cluster Support) 🌐

Most enterprises operate multiple Kubernetes clusters for development, staging, production, etc. This plugin connects to all configured clusters and gathers relevant data.

2. Entity Mapping (Service-to-Cluster Mapping) 🔗

This is the most important feature! It matches a specific ‘service’ registered in the Backstage catalog with its corresponding ‘resource’ on Kubernetes. Data is usually filtered based on the backstage.io/kubernetes-id label set in the YAML file.

3. Authentication and Security (Authentication) 🔐

It handles authentication methods such as Service Account tokens, cluster certificates, or cloud provider (AWS EKS, GCP GKE, etc.) authentication to securely access each cluster.

🛠️ How to Install and Configure?

Here’s how to enable this plugin in a Backstage monorepo structure:

Step 1: Install Package 📦

Add the library to your backend package in the terminal.

Bash

yarn workspace backend add @backstage/plugin-kubernetes-backend

Step 2: Register Backend Code ⚙️

For the latest Backstage system (New Backend System), add the following to packages/backend/src/index.ts.

TypeScript

backend.add(import('@backstage/plugin-kubernetes-backend/alpha'));

Step 3: Configure app-config.yaml 📝

This is the most crucial part. You need to specify which clusters to connect to and how.

YAML

kubernetes:
  serviceLocatorMethod:
    type: 'multiTenant'
  clusterLocatorMethods:
    - type: 'config'
      clusters:
        - url: https://<apiserver-url>
          name: my-cluster
          authProvider: 'serviceAccount'
          skipTLSVerify: false
          # ... other authentication settings

🔍 Perfect Match with Frontend: plugin-kubernetes

While the backend plugin fetches data, the dazzling dashboard users see is handled by @backstage/plugin-kubernetes (the frontend plugin). 🎨

Backend: Communicates with cluster APIs to fetch JSON data.
Frontend: Visualizes Pod status (Running, Error, etc.) and displays logs based on the fetched data.

💡 Practical Tip: Why Can’t I See My Service? 🤔

If you’ve installed the plugin but can’t see any data, check these two things:

Check Label: Does your service’s Kubernetes resource (Deployment, etc.) have the backstage.io/kubernetes-id: label?
Check Annotation: Is the backstage.io/kubernetes-id: annotation added to your Backstage catalog-info.yaml file?

These two IDs must match for the backend plugin to recognize, “Ah! This Pod belongs to this service!” ✨

🏁 Conclusion: Completing Infrastructure Visibility

@backstage/plugin-kubernetes-backend is a key tool for integrating fragmented infrastructure information into a developer-centric view. Through this plugin, developers can build a Self-service environment where they can check the status of their services themselves without having to contact the infrastructure department! 🚀
